Drive Axle for Forklifts - A lift truck drive axle is actually a piece of equipment that is elastically affixed to a vehicle framework using a lift mast. The lift mast is connected to the drive axle and is capable of being inclined round the axial centerline of the drive axle. This is done by at the very least one tilting cylinder. Frontward bearing components together with rear bearing parts of a torque bearing system are responsible for fastening the vehicle and the drive axle framework. The drive axle can be pivoted around a swiveling axis oriented horizontally and transversely in the vicinity of the back bearing elements. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is attached to the vehicle framework and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented nearly parallel to a plane extending from the swiveling axis to the axial centerline.
Unit H40, H45 and H35 forklifts, that are manufactured by Linde AG in Aschaffenburg, Germany, have a connected lift mast tilt on the vehicle frame itself. The drive axle is elastically connected to the frame of the forklift by many different bearings. The drive axle has tubular axle body along with extension arms attached to it and extend backwards. This particular kind of drive axle is elastically affixed to the vehicle framework using back bearing parts on the extension arms together with frontward bearing tools located on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the lift truck from the other bearing machine in its respective pair.
The braking and drive torques of the drive axle on this unit of lift truck are sustained utilizing the extension arms through the rear bearing components on the frame. The forces generated by the load being carried and the lift mast are transmitted into the floor or road by the vehicle framework through the front bearing components of the drive axle. It is essential to make sure the elements of the drive axle are installed in a rigid enough manner in order to maintain strength of the forklift truck. The bearing elements can reduce small road surface irregularities or bumps all through travel to a limited extent and provide a bit smoother operation.
